Aerodyne Pilot 9
Canopy Details
Type:
Main Canopy
Sizes:
90 - 250
Build:
9 cells
Aspect Ratio:
2.51:1
Wingloading Range:
1.0 - 1.80
Fabric:
ZP or ZPX or UltraLPV
Line Type:
600 Dacron or 700 Vectran ZLX or 725 Spectra
MSRP:
$2760 USD
User Category:
Student Novice Experienced Expert
Documents
-
line trim02/06/2025
-
Line Trim (imperial)06/12/2023
-
Line Trim (metric)06/12/2023
-
Technical Specs & Sizes16/06/2023
-
Semi stowless bag09/06/2023
-
Manual01/12/2020
Note: Documents are provided by manufacturers and may not be available for all canopies. If you have a document to share, please contact us.
Canopy Sizes
| Size (sqft) |
Span (ft) |
Chord (min/max ft) |
Weight (lbs) |
Packing Volume (cu in) |
|---|---|---|---|---|
| 90 | 15.3 | 5.3 / 6.27 | 4.74 | 304 |
| 96 | 15.51 | 5.4 / 6.36 | 4.88 | 314 |
| 104 | 16.16 | 5.63 / 6.62 | 5.08 | 327 |
| 111 | 16.54 | 5.76 / 6.78 | 5.24 | 337 |
| 117 | 16.91 | 5.89 / 6.93 | 5.39 | 347 |
| 124 | 17.64 | 6.15 / 7.23 | 5.46 | 351 |
| 132 | 18.2 | 6.35 / 7.46 | 5.63 | 368 |
| 140 | 18.74 | 6.54 / 7.67 | 5.79 | 379 |
| 150 | 19.4 | 6.77 / 7.95 | 6.01 | 393 |
| 168 | 20.53 | 7.16 / 8.42 | 6.34 | 416 |
| 188 | 21.72 | 7.58 / 8.9 | 6.71 | 440 |
| 210 | 22.95 | 8.01 / 9.41 | 7.08 | 465 |
| 230 | 24 | 8.39 / 9.85 | 7.41 | 486 |
| 250 | 25.95 | 8.71 / 10.2 | 7.74 | 501 |
Note: Data gathered from manufacturer specifications.
N/A = manufacturer doesn't share this data.
Packing volume can vary based on technique and environmental factors.
Measuring techniques may vary between manufacturers, so values may not be directly comparable.
