Performance Designs Katana
We are working on getting a description for this canopy.
If you have one to share, please contact us.
Canopy Sizes
| Size (sqft) |
Span (ft) |
Chord (min/max ft) |
Weight (lbs) |
Packing Volume (cu in) |
|---|---|---|---|---|
| 83 | 15.08 | 4.04 / 5.94 | N/A | N/A |
| 89 | 15.62 | 4.19 / 6.15 | N/A | N/A |
| 97 | 16.3 | 4.37 / 6.42 | N/A | 234 |
| 107 | 17.12 | 4.59 / 6.74 | N/A | 273 |
| 120 | 18.13 | 4.86 / 7.14 | N/A | 312 |
| 135 | 19.23 | 5.15 / 7.57 | N/A | 338 |
| 150 | 20.27 | 5.43 / 7.98 | N/A | 364 |
| 170 | 21.58 | 5.78 / 8.5 | N/A | 385 |
| 190 | 22.56 | 6.31 / 9.03 | N/A | 475 |
Note: Data gathered from manufacturer specifications.
N/A = manufacturer doesn't share this data.
Packing volume can vary based on technique and environmental factors.
Measuring techniques may vary between manufacturers, so values may not be directly comparable.
Canopy Details
- Type:
- Main Canopy
- Sizes:
- 83 - 190
- MSRP:
- $3250 USD
- Build:
- 9 cells
- Aspect Ratio:
- 2.74:1
- Wingloading Range:
- N/A
- Fabric:
- ZP
- Line Type:
- HMA 500 HMA 700
- Produced between:
- 2004 - N/A
- User Category:
- Student Novice Experienced Expert
- Keywords:
- elliptical
Documents
-
Wing loading chartPNG - 19/06/2025
-
Packing instructions04/04/2019
-
Measuring linetrims21/05/2008
-
Manual01/12/2004
-
Line Trim02/08/2023
Note: Documents are provided by manufacturers and may not be available for every gear item. If you have a document to share, please contact us.
