Aerodyne Triathlon Hybrid
Canopy Details
Type:
Main Canopy
Sizes:
99 - 300
Build:
7 cells
Aspect Ratio:
2.0:1
Wingloading Range:
1.0 - 2.20
Fabric:
ZP or ZPX
Line Type:
725 Spectra / 600 Dacron
MSRP:
$2700 USD
Keywords:
CRW
Documents
-
Technical Specs & Sizes16/06/2023
-
Line Trim (Imperial)12/06/2023
-
Line Trim (Spectra Metric)12/06/2023
-
Attaching a CRW bridle09/06/2023
-
Manual01/12/2020
-
Line Trim (Spectra Metric)11/09/2008
Note: Documents are provided by manufacturers and may not be available for all canopies. If you have a document to share, please contact us.
Canopy Sizes
| Size (sqft) |
Span (ft) |
Chord (min/max ft) |
Weight (lbs) |
Packing Volume (cu in) |
|---|---|---|---|---|
| 99 | 14.12 | 7.05 | 3.96 | 242 |
| 120 | 15.5 | 7.74 | 4.84 | 316 |
| 135 | 16.43 | 8.2 | 5.28 | 349 |
| 150 | 17.33 | 8.65 | 5.72 | 370 |
| 160 | 17.83 | 8.9 | 6.16 | 390 |
| 175 | 18.67 | 9.32 | 6.38 | 405 |
| 190 | 19.46 | 9.71 | 6.82 | 420 |
| 210 | 20.25 | 10.11 | 7.04 | 435 |
| 220 | 20.9 | 10.45 | 7.26 | 462 |
| 230 | 21.45 | 10.73 | 7.3 | 466 |
| 240 | 21.91 | 10.96 | 7.45 | 470 |
| 250 | 22.4 | 11.2 | 7.5 | 473 |
| 260 | 22.83 | 11.42 | 7.7 | 485 |
| 270 | 23.24 | 11.52 | 7.8 | 488 |
| 280 | 23.27 | 11.6 | 7.86 | 495 |
| 290 | 24.09 | 12.05 | 7.95 | 500 |
| 300 | 24.75 | 12.38 | 8.01 | 505 |
Note: Data gathered from manufacturer specifications.
N/A = manufacturer doesn't share this data.
Packing volume can vary based on technique and environmental factors.
Measuring techniques may vary between manufacturers, so values may not be directly comparable.
